1Megapixel CMOS

25/30fps@720P

High speed, long distance real-time transmission

Day/Night(ICR), AWB, AGC, BLC, 2D-DNR

3.6mm fixed lens

Max. IR LEDs length 15m, Smart IR

DC12V

Technical Specifications:

-------------------------

Model: DH-HAC-HDW1000RP, DH-HAC-HDW1000RN

Camera:

------

Image Sensor: 1Megapixel CMOS

Effective Pixels: 1280(H)×720(V)

Electronic Shutter: 1/50s~1/100,000s

Video Frame Rate: 25fps@720P

Synchronization: Internal

Video Output: 1-channel BNC HDCVI high definition video output

Camera Features:

----------------

Max. IR LEDs Length: 15m, Smart IR

Day/Night: Auto(ICR) / Color / B/W

Noise Reduction: 2D

Lens:

-----

Focal Length: 3.6mm fixed lens

Angle of View: H: 59º

Mount Type: M12

General:

-------

Power Supply: DC12V±20%

Power Consumption: Max 2.5W

Working Environment: -30°C~+60°C / Less than 95%RH (no condensation)

Transmission Distance: Over 800m via 75-3 coaxial cable

Dimensions: Φ85mm×69mm

Weight: 0.1kg

Material: Plastic
