5mm IR LED Transmitter-10Pcs
- IR EMITTER, 940NM, 5MM, THROUGH HOLE
- Peak Wavelength:940nm
- Forward Current If(AV):100mA
- Rise Time:800ns
- Fall Time tf:800ns
- Radiant Intensity:45mW/Sr
- Viewing Angle:22°
- Forward Voltage VF Max:1.35V
- Operating Temperature Min:-40°C
- Operating Temperature Max:85°C
- Diode Case Style:T-1 3/4 (5mm)
- No. of Pins:2
- Packaging:Each
- MSL:–
- Angle of Half Sensitivity ±:22°
- Current If @ Vf:100mA
- External Diameter:5.8mm
- External Length / Height:8.7mm
- LED / Lamp Size:5mm
- Lead Diameter:0.5mm
- Lead Length:25.7mm
- Lead Spacing:2.54mm
- Operating Temperature Range:-40°C to +85°C
- PIV Max:5V
- Peak Forward Current:200mA
- Peak Pulse Current Ippm:1.5mA
- Radiant Intensity Max:150mW/Sr
- Radiant Intensity Min:30mW/Sr
- Radiometric Power:35mW
- Reverse Leakage Current Max:10µA
- Storage Temperature Max:100°C
- Storage Temperature Min:-55°C
- Voltage Vf Typ:1.35V
- Wavelength Typ:950nm
