APOLLO ONLINE UPS 2600HS
Product Code: APOLLO 2600HS 6.0KVA EPS Power 6KVA/4.2kW Voltage Input: 220VAC Nominal Voltage II Output: 220VAC±1% Voltage Voltage Range 60～138VAC/115～300VAC Charging Current 8hrs to90%of capacity after full load discharge Warranty 1 Year Description APOLLO 2600HS 6.0KVA UPSVA: 6KVA Input: 220VAC Nominal Voltage FrequencyRange: 46～54Hz(default),user adjustable within 40～60Hz PowerFactor: 0.97 VoltageRange: 176～276VAC Output: 220VAC±1% Voltage Frequency: 46-54Hz±0.2Hz(Line mode) 50Hz±0.2Hz(battery mode) Waveform: sine wave Distortion: ≤2% under linear load PowerFactor: 0.7 Battery: Sealed, Maintenance free, Lead-Acid Recharge Time: 8hrs to90%of capacity after full load discharge LED/LCD Indicators: status: load level/Battery level, Battery, Utility power, Inverter, Bypass, Overload, Fault Audible Alarm: Bypass, ON battery mode, Battery low, Overload, Fault Acoustic Noise: 55 dBA Weight: 90/35 kg Dimensions: 260*570*717 W×D×H (mm)
Product Code: APOLLO 2600HS 6.0KVA
EPS
Power 6KVA/4.2kW
Voltage Input: 220VAC Nominal Voltage II Output: 220VAC±1% Voltage
Voltage Range 60～138VAC/115～300VAC
Charging Current 8hrs to90%of capacity after full load discharge
Warranty 1 Year
Description APOLLO 2600HS 6.0KVA UPSVA: 6KVA
Input: 220VAC Nominal Voltage
FrequencyRange: 46～54Hz(default),user adjustable within 40～60Hz
PowerFactor: 0.97
VoltageRange: 176～276VAC
Output: 220VAC±1% Voltage
Frequency: 46-54Hz±0.2Hz(Line mode) 50Hz±0.2Hz(battery mode)
Waveform: sine wave
Distortion: ≤2% under linear load
PowerFactor: 0.7
Battery: Sealed, Maintenance free, Lead-Acid
Recharge Time: 8hrs to90%of capacity after full load discharge
LED/LCD Indicators:
status: load level/Battery level, Battery, Utility power, Inverter, Bypass, Overload, Fault
Audible Alarm: Bypass, ON battery mode, Battery low, Overload, Fault
Acoustic Noise: 55 dBA
Weight: 90/35 kg
Dimensions: 260*570*717 W×D×H (mm)
