Video Output Mode: AHD

Image Sensor: V20E+H2

Image Resolution: 1.0MP/720

Effective Pixels: 1280*720

TV System: PAL/NTSC

Electronic Shutter: 1/25s~1/50,000s , 1/30s~1/60,000s

S/N Ratio: ≥50dB

Scanning System: Progressive Scan

Focus Length: Board Lens 3.6mm

Focus Control: Fixed

Lens Type: Fixed

Pixels: 1.0M Pixels

Auto Iris Support: NO

Infrared LED: 14µ x 36PCS

Infrared Distance: 25M

IR Status: Under 10 Lux by CDS

IR Power On: CDS Auto Control

Starlight: NO

Day/Night: YES

White Balance: AUTO

Gain Control: AUTO

Noise Reduction: DNR

Picture Adjustment: YES

WDR: YES

OSD Support: NO

UTC: NO

Dip Switch: NO

Housing: IP66

Bracket: YES

Dual Voltage: NO

IR Cut Filter: YES

Heater: NO

Audio: NO

Operation Temperature : -10℃ ~ +50℃ RH95% Max

Storage Temperature: -20℃ ~ +60℃ RH95% Max

Power Source: DC12V±10%, 1000mA

Dimension: 157(W) x 70(H) x 66(D)mm

Weight: 310g
