Kyoritsu 4105A Digital Earth Tester Multimeter Resistance Meter
Kyoritsu 4105A ডিজিটাল আর্থ টেস্টার Multimeter Resistance Meter
KYORITSU 4105A-H Digital Earth Resistance Tester
1.Dust and drip proof.(designed to IEC 529 IP54)
2.In addition to the facility for precision measurement, test leads for simplified two wire easuring system also supplied as standard accessories.
(unit can be hung from the neck for simplified measurement)
3.Designed to meet IEC 61010-1 safety standard.
4.Capable of measuring earth voltage.
5.Automatic warning when resistance of auxiliary earth spikes is in excess of tolerance.
6.Small and lightweight. Shock resistant new case material.
7.2mA measuring current permits earth resistance tests without tripping earth leakage current breakers in the circuit under test.
Parameter:
Measurement ranges
Earth Resistance: 0 – 20Ω/0 – 200Ω/0 – 2000Ω
Earth Voltage [50,60Hz]: 0 – 200V AC
Earth Resistance: ±2%rdg±0.1Ω (20Ωrange)
±2%rdg±3dgt (200Ω/2000Ωrange)
Earth Voltage: ±1%rdg±4dgt
Overload protection Earth Resistance: 280V AC for 10 seconds
across 2 of the 3 terminals
Earth Voltage: 300V AC for 1 minute
Applicable standards IEC 60529 IP54
Safety Standard IEC 61010-1 CAT III 300V Pollution Degree 2, IEC 61557
Power source R6 (AA) (1.5V) × 6
(Not included)
Dimensions 105(L) × 158(W) × 70(D)mm
Weight 550g approx
Included Accessories 7095A (Earth resistance test leads) × 1set
(red-20m, yellow-10m, green-5m)
8032 (Auxiliary earth spikes) × 1set
7127A (Simplified measurement probe) × 1set
9121 (Shoulder strap)
Instruction Manual
Carrying case : 9084(Carrying case[Soft]:4105A only)
: 9165(Carrying case[Hard]:4105A-H only)
