LM311 Differential Comparator IC SOP8 DIP
- Low input bias current : 250nA (Max)
- Low input offset current : 50nA (Max)
- Differential Input Voltage : ±30V
- Power supply voltage : single 5.0V supply to ±15V.
- Offset voltage null capability.
- Strobe capability.
- Maximum Supply Voltage:36V
- Output to Negative Supply Voltage:40 V
- Ground to Negative voltage : -30 V
- Differential Input Voltage : 30 V
- Input Voltage :±15 V
- Maximum Power Dissipation:500mW
- Maximum Positive Supply Current:7.5mA
- Maximum Negative supply current:-5mA
- Operating Temperature range:0~+70°C
