PNP Transistor BD 140 (2 piece)
PNP ট্রান্সিস্টর BD 140 (2 piece)
Type Designator: BD140
Material of Transistor: Si
Polarity: PNP
Maximum Collector Power Dissipation (Pc): 12 W
Maximum Collector-Base Voltage |Vcb|: 80 V
Maximum Collector-Emitter Voltage |Vce|: 80 V
Maximum Emitter-Base Voltage |Veb|: 5 V
Maximum Collector Current |Ic max|: 1 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 50 MHz
Forward Current Transfer Ratio (hFE), MIN: 40
Noise Figure, dB: -
Package: TO126
Cross-Reference Search Result (Equivalent Transistors)
