Siemens 16A 3 Pole Miniature Circuit Breaker
Siemens 16A 3 Pole মিনিয়েচার সার্কিট ব্রেকার
Description
Siemens Miniature Circuit Breaker MCB 16A type B 3- Pole 6KA 400V
Electrical specifications
Voltage: AC/ DC
Minimum: 24V
By DC: 60V
Supply Voltage: 50Hz
Isolation Voltage: Multiphase 440V+
General specifications
Number of Pole: 3
Release characteristic: B
Rated Current: 16A
Mechanical durability: 20.000
Overvoltage category: 3
Power:
Switching capacity power: 6kA in accordance with EN 60898, IEC 60947-2
Power dissipation: (W): 1,9W if AC / max. 5,7W
Safety:
Protection degree: IP20, with connected conductors
Limiting Energy type: 3
Ambient Temperature: -25°C to +45°C
Measurements:
High: 90mm
Width: 54mm
Depth: 76mm
Installation depth: 70mm
Cross section: 0,75mm² to 35mm²
Product certification:
CEBEC
CCC
IMQ
VDE
EAC
CE
Halogen free
Silicone free
Sealable
The Siemens Residual Current operated Circuit-Breaker (RCCB) are intended for use up to 6kA and offers person and plants protection effectively by shutting down safely, while overload or short circuit.
They are useful to build quick and simple additional components, like auxiliary power and fault signal contacts. It can be combined with operating power, under voltage release and fire protection switch.
To simplify the introduction of conductors, the Circuit breaker has a terminal design for receiving pin bushbars to combine other conductors up to 35mm² together.
The rated current range is between 10A to 32A and are available in B and C characteristic.
You can find RCCB and MCB´s in our online shop under the following category “Installation”
