Speed: 300Mbps

Frequency: 2.4GHz 2.4GHz

Interface: 1 x WAN & 4 x LAN ports
HARDWARE FEATURES

Interface 4 10/100Mbps LAN PORTS

1 10/100Mbps WAN PORT

Button WPS/RESET Button

External Power Supply 9VDC / 0.6A

Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Dimensions ( W x D x H ) 7.2 x 5.0 x 1.4in.(182 x 128 x 35 mm)

Antenna 2 Antennas

WIRELESS FEATURES

Frequency 2.4-2.4835GHz

Signal Rate 11n: Up to 300Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

Reception Sensitivity 270M: -68dBm@10% PER

130M: -68dBm@10% PER

108M: -68dBm@10% PER

54M: -68dBm@10% PER

11M: -85dBm@8% PER

6M: -88dBm@10% PER

1M: -90dBm@8% PER

Transmit Power CE:

<20dBm

FCC:

<30dBm

Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

Wireless Security 64/128-bit WEP, WPA / WPA2,WPA-PSK / WPA2-PSK

SOFTWARE FEATURES

Quality of Service WMM, Bandwidth Control

WAN Type Dynamic IP/Static IP/PPPoE/

PPTP/L2TP

Management Access Control

Local Management

Remote Management

DHCP Server, Client, DHCP Client List,

Address Reservation

Port Forwarding Virtual Server,Port Triggering, UPnP, DMZ

Dynamic DNS DynDns, Comexe, NO-IP

VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)

Access Control Parental Control, Local Management Control, Host List, Access Schedule, Rule Management

Firewall Security DoS, SPI Firewall

IP Address Filter/MAC Address Filter/Domain Filter

IP and MAC Address Binding

Protocols Support IPv4 and IPv6

Guest Network 2.4GHz Guest Network x1

OTHERS

Certification CE, RoHS

Package Contents Wireless N Router TL-WR840N

Power supply unit

Resource CD

Ethernet Cable

Quick Installation Guide

System Requirements Windows 2000/XP/Vista™, Windows 7, Windows 8, Windows 8.1, Windows 10 or Mac OS or Linux-based operating system

Environment Operating Temperature: 0℃~40℃ (32℉~10
