HARDWARE FEATURES

Interface 4 10/100Mbps

LAN PORTS 1 10/100Mbps

WAN PORT Button

WPS/RESET Button

Antenna 2 Antennas

External Power Supply 9VDC / 0.6A

Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Dimensions ( W x D x H ) 7.2 x 5.0 x 1.4in.(182 x 128 x 35 mm)

WIRELESS FEATURES Frequency 2.4-2.4835GHz

Signal Rate 11n: Up to 300Mbps(dynamic) 11g: Up to 54Mbps(dynamic) 11b: Up to 11Mbps(dynamic)

Reception Sensitivity 270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER Transmit Power <20dBm FCC: <30dBm

Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM,

Wireless Statistics Wireless Security 64/128-bit WEP, WPA / WPA2,WPA-PSK / WPA2-PSK
